MainActivity.kt
package com.example.jetpack
import android.content.Context
import android.graphics.Color
import android.graphics.Typeface
import android.graphics.drawable.ColorDrawable
import android.os.Bundle
import android.util.TypedValue
import android.view.View
import android.widget.TextView
import androidx.appcompat.app.AppCompatActivity
import androidx.constraintlayout.widget.ConstraintLayout
import androidx.constraintlayout.widget.ConstraintLayout.LayoutParams
import androidx.constraintlayout.widget.ConstraintLayout.LayoutParams.PARENT_ID
import androidx.constraintlayout.widget.ConstraintSet
import androidx.core.widget.TextViewCompat
import kotlinx.android.synthetic.main.activity_main.*
class MainActivity : AppCompatActivity() {
override fun onCreate(savedInstanceState: Bundle?) {
super.onCreate(savedInstanceState)
setContentView(R.layout.activity_main)
val context = this
val string = "Lorem Ipsum is simply dummy text of the printing" +
" and typesetting industry."
createTextView().apply {
text = string
constraintLayout.addViewCenter(context,this)
}
}
}
// extension function to create a text view programmatically
fun Context.createTextView():TextView{
return TextView(this).apply {
text = "Sample TextView" // text
// set text view text appearance
TextViewCompat.setTextAppearance(
this,
android.R.style.TextAppearance_DeviceDefault_Large
)
// set text appearance or individually set styles
typeface = Typeface.MONOSPACE // font
background = ColorDrawable(Color.parseColor("#FFFAF0")) // background color
setTextColor(Color.parseColor("#A2006D")) // text color
setTypeface(typeface, Typeface.ITALIC) // text style
setTextSize(TypedValue.COMPLEX_UNIT_SP,30F) // text size
val padding = 25.dpToPixels(this@createTextView)
setPadding(padding,padding,padding,padding) // padding
// text view width and height
layoutParams = LayoutParams(
LayoutParams.MATCH_PARENT, // width
LayoutParams.WRAP_CONTENT // height
)
// generate a view id for text view
id = View.generateViewId()
}
}
// extension function to add view to constraint layout center
fun ConstraintLayout.addViewCenter(context:Context, view:View){
addView(view)
// initialize a new constraint set
val set = ConstraintSet()
set.clone(this)
val margin = 16.dpToPixels(context)
// put view center in parent
set.connect(view.id,ConstraintSet.START,PARENT_ID,
ConstraintSet.START,margin)
set.connect(view.id,ConstraintSet.TOP,PARENT_ID,ConstraintSet.TOP)
set.connect(view.id,ConstraintSet.END,PARENT_ID,
ConstraintSet.END,margin)
set.connect(view.id,ConstraintSet.BOTTOM,PARENT_ID,ConstraintSet.BOTTOM)
// finally, apply the constraint set to constraint layout
set.applyTo(this)
}
// extension function to convert dp to pixels
fun Int.dpToPixels(context: Context):Int = TypedValue.applyDimension(
TypedValue.COMPLEX_UNIT_DIP,this.toFloat(),context.resources.displayMetrics
).toInt()
activity_main.xml
<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout
xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
xmlns:tools="http://schemas.android.com/tools"
android:id="@+id/constraintLayout"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:background="#EDEAE0"
tools:context=".MainActivity"/>
