android kotlin - MaterialCardView border color width radius example

MainActivity.kt

package com.example.jetpack

import android.content.Context
import android.graphics.Color
import android.os.Bundle
import android.util.TypedValue
import androidx.appcompat.app.AppCompatActivity
import kotlinx.android.synthetic.main.activity_main.*


class MainActivity : AppCompatActivity() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_main)

        // programmatically draw card border
        materialCardView2.apply {
            // border color
            strokeColor = Color.parseColor("#007FFF")
            // border width in dp
            strokeWidth = 4.toDp(context)
            // card corner radius
            radius = 12.toDp(context).toFloat()
        }
    }
}

// extension method to convert pixels to dp
fun Int.toDp(context: Context):Int = TypedValue.applyDimension(
    TypedValue.COMPLEX_UNIT_DIP,this.toFloat(),context.resources.displayMetrics
).toInt()
activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/constraintLayout"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".MainActivity">

    <com.google.android.material.card.MaterialCardView
        android:id="@+id/materialCardView1"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_marginStart="24dp"
        android:layout_marginTop="24dp"
        android:layout_marginEnd="24dp"
        app:cardBackgroundColor="#FFBF00"
        app:cardElevation="16dp"
        app:cardCornerRadius="12dp"
        app:contentPadding="16dp"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toTopOf="parent"
        app:strokeColor="#E52B50"
        app:strokeWidth="4dp">

        <com.google.android.material.textview.MaterialTextView
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:text="Border Color In XML"
            android:textAppearance=
                "@style/TextAppearance.MaterialComponents.Headline3" />

    </com.google.android.material.card.MaterialCardView>

    <com.google.android.material.card.MaterialCardView
        android:id="@+id/materialCardView2"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_marginStart="24dp"
        android:layout_marginTop="24dp"
        android:layout_marginEnd="24dp"
        app:cardBackgroundColor="#89CFF0"
        app:cardElevation="16dp"
        app:contentPadding="16dp"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toBottomOf="@id/materialCardView1">

        <com.google.android.material.textview.MaterialTextView
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:text="Material Card Border Programmatically."
            android:textAppearance=
                "@style/TextAppearance.MaterialComponents.Headline4" />

    </com.google.android.material.card.MaterialCardView>

</androidx.constraintlayout.widget.ConstraintLayout>
