android - Media Player SeekBar example

activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:background="#ecc8ef"
    android:padding="16dp"
    android:orientation="vertical"
    >
    <RelativeLayout
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        >
        <TextView
            android:id="@+id/tv_pass"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            />
        <TextView
            android:id="@+id/tv_duration"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:layout_centerHorizontal="true"
            />
        <TextView
            android:id="@+id/tv_due"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:layout_alignParentRight="true"
            android:layout_alignParentEnd="true"
            />
        <SeekBar
            android:id="@+id/seek_bar"
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:layout_below="@id/tv_pass"
            />
    </RelativeLayout>
    <LinearLayout
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:orientation="horizontal"
        >
        <Button
            android:id="@+id/btn_play"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:text="Start"
            />
        <Button
            android:id="@+id/btn_stop"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:text="Stop"
            />
    </LinearLayout>
</LinearLayout>
MainActivity.java

package com.cfsuman.me.androidcodesnippets;

import android.app.Activity;
import android.content.Context;
import android.media.MediaPlayer;
import android.os.Handler;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.View;
import android.widget.Button;
import android.widget.SeekBar;
import android.widget.TextView;
import android.widget.Toast;


public class MainActivity extends AppCompatActivity {
    private Context mContext;
    private Activity mActivity;

    private Button mButtonPlay;
    private Button mButtonStop;

    private SeekBar mSeekBar;

    private TextView mPass;
    private TextView mDuration;
    private TextView mDue;

    private MediaPlayer mPlayer;
    private Handler mHandler;
    private Runnable mRunnable;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        // Get the application context
        mContext = getApplicationContext();
        mActivity = MainActivity.this;

        // Get the widget reference from xml layout
        mButtonPlay = findViewById(R.id.btn_play);
        mButtonStop = findViewById(R.id.btn_stop);
        mSeekBar = findViewById(R.id.seek_bar);
        mPass = findViewById(R.id.tv_pass);
        mDuration = findViewById(R.id.tv_duration);
        mDue = findViewById(R.id.tv_due);

        // Initialize the handler
        mHandler = new Handler();

        // Click listener for playing button
        mButtonPlay.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                // If media player another instance already running then stop it first
                stopPlaying();

                // Initialize media player
                mPlayer = MediaPlayer.create(mContext,R.raw.my_favorite_song);

                // Start the media player
                mPlayer.start();
                Toast.makeText(mContext,"Media Player is playing.",Toast.LENGTH_SHORT).show();

                // Get the current audio stats
                getAudioStats();
                // Initialize the seek bar
                initializeSeekBar();

            }
        });

        // Set a click listener for top playing button
        mButtonStop.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                stopPlaying();
            }
        });

        /*
            SeekBar.OnSeekBarChangeListener
                A callback that notifies clients when the progress level has been changed. This
                includes changes that were initiated by the user through a touch gesture or
                arrow key/trackball as well as changes that were initiated programmatically.
        */

        // Set a change listener for seek bar
        mSeekBar.setOnSeekBarChangeListener(new SeekBar.OnSeekBarChangeListener() {
            /*
                void onProgressChanged (SeekBar seekBar, int progress, boolean fromUser)
                    Notification that the progress level has changed. Clients can use the fromUser
                    parameter to distinguish user-initiated changes from those that occurred programmatically.

                Parameters
                    seekBar SeekBar : The SeekBar whose progress has changed
                    progress int : The current progress level. This will be in the range min..max
                                   where min and max were set by setMin(int) and setMax(int),
                                   respectively. (The default values for min is 0 and max is 100.)
                    fromUser boolean : True if the progress change was initiated by the user.
            */
            @Override
            public void onProgressChanged(SeekBar seekBar, int i, boolean b) {
                if(mPlayer!=null && b){
                    /*
                        void seekTo (int msec)
                            Seeks to specified time position. Same as seekTo(long, int)
                            with mode = SEEK_PREVIOUS_SYNC.

                        Parameters
                            msec int: the offset in milliseconds from the start to seek to

                        Throws
                            IllegalStateException : if the internal player engine has not been initialized
                    */
                    mPlayer.seekTo(i*1000);
                }
            }

            @Override
            public void onStartTrackingTouch(SeekBar seekBar) {

            }

            @Override
            public void onStopTrackingTouch(SeekBar seekBar) {

            }
        });
    }

    protected void stopPlaying(){
        // If media player is not null then try to stop it
        if(mPlayer!=null){
            mPlayer.stop();
            mPlayer.release();
            mPlayer = null;
            Toast.makeText(mContext,"Stop playing.",Toast.LENGTH_SHORT).show();
            if(mHandler!=null){
                mHandler.removeCallbacks(mRunnable);
            }
        }
    }

    /*
        int getDuration ()
            Gets the duration of the file.

        Returns
            int the duration in milliseconds, if no duration is available
            (for example, if streaming live content), -1 is returned.
    */

    /*
        int getCurrentPosition ()
            Gets the current playback position.

        Returns
            int the current position in milliseconds
    */

    protected void getAudioStats(){
        int duration  = mPlayer.getDuration()/1000; // In milliseconds
        int due = (mPlayer.getDuration() - mPlayer.getCurrentPosition())/1000;
        int pass = duration - due;

        mPass.setText("" + pass + " seconds");
        mDuration.setText("" + duration + " seconds");
        mDue.setText("" + due + " seconds");
    }

    protected void initializeSeekBar(){
        mSeekBar.setMax(mPlayer.getDuration()/1000);

        mRunnable = new Runnable() {
            @Override
            public void run() {
                if(mPlayer!=null){
                    int mCurrentPosition = mPlayer.getCurrentPosition()/1000; // In milliseconds
                    mSeekBar.setProgress(mCurrentPosition);
                    getAudioStats();
                }
                mHandler.postDelayed(mRunnable,1000);
            }
        };
        mHandler.postDelayed(mRunnable,1000);
    }
}
