activity_main.xml
<RelativeLayout
xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:tools="http://schemas.android.com/tools"
android:id="@+id/rl"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:padding="16dp"
tools:context=".MainActivity"
android:background="@android:color/white"
>
<Button
android:id="@+id/btn"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:text="Align Parent Right"
/>
</RelativeLayout>
MainActivity.java
package com.cfsuman.me.androidcodesnippets;
import android.os.Bundle;
import android.app.Activity;
import android.view.View;
import android.widget.Button;
import android.widget.RelativeLayout;
import android.widget.RelativeLayout.LayoutParams;
public class MainActivity extends Activity{
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main);
// Get the widgets reference from XML layout
RelativeLayout rl = (RelativeLayout) findViewById(R.id.rl);
final Button btn = (Button) findViewById(R.id.btn);
// Set a click listener for Button widget
btn.setOnClickListener(new View.OnClickListener() {
@Override
public void onClick(View v) {
/*
LayoutParams are used by views to tell
their parents how they want to be laid out
public ViewGroup.LayoutParams getLayoutParams ()
Get the LayoutParams associated with this view.
All views should have layout parameters.
These supply parameters to the parent of this view
specifying how it should be arranged. There are many
subclasses of ViewGroup.LayoutParams, and these correspond
to the different subclasses of ViewGroup that are
responsible for arranging their children.
*/
LayoutParams lp = (LayoutParams) btn.getLayoutParams();
/*
addRule(int verb)
Adds a layout rule to be interpreted by the RelativeLayout.
This method should only be used for constraints that don't
refer to another sibling (e.g., CENTER_IN_PARENT) or take
a boolean value (TRUE for true or 0 for false).
addRule(int verb, int anchor)
Adds a layout rule to be interpreted by the RelativeLayout.
Use this for verbs that take a target, such as a sibling
(ALIGN_RIGHT) or a boolean value (VISIBLE).
ALIGN_PARENT_RIGHT
Rule that aligns the child's right edge
with its RelativeLayout parent's right edge.
*/
lp.addRule(RelativeLayout.ALIGN_PARENT_RIGHT);
/*
public void setLayoutParams (ViewGroup.LayoutParams params)
Set the layout parameters associated with this view.
These supply parameters to the parent of this view specifying
how it should be arranged. There are many subclasses of
ViewGroup.LayoutParams, and these correspond to the different
subclasses of ViewGroup that are responsible
for arranging their children.
*/
btn.setLayoutParams(lp);
}
});
}
}
